Middleby Marshall PS638 Gas or Electric WOW! Impingement Conveyor Oven - Single/Double/ Triple Stack options Available - Single Stack
⍰ Contact us to confirm availability @ 408-673-9999 or sales@celebratefestivalinc.com
⍰ For Pricing - contact us @ 408-673-9999 or sales@celebratefestivalinc.com
Dimensions:
| Heating Zone | 38” | 965 mm |
| Baking Area | 6.8 sq ft² | 0.63 sq m |
| Belt Length | 65.25” | 1657 mm |
| Overall Length | 65.25” | 1657 mm |
| Height (22.13”/562 mm legs)* | * 41.9” | 1064 mm |
| Depth | 49.23” | 1250 mm |
| Ship Weight | 820 lb. | 372 kg |
| Ship Cube | 115 ft³ | 3.24 m³ |
Specifications:
Standard Features:
- Impingement PLUS! low oven profile and dual air return
- Reduces energy consumption and increases cooking efficiency
- 38” (965 mm) long baking chamber
- 26” (660 mm) wide, 65.25”(1657 mm) long conveyor belt
- Removable parts for easy cleaning (crumb pans, end panels, air fingers, and a folding conveyor belt assembly)
- The control compartment is designed for quick and easy access
- Advanced technology air delivery system bakes up to 30% faster than standard conveyor ovens
- For installation under a ventilation hood only
- Optional Features: Split belt – two 12” (305mm) belts with individually adjustable speed settings
